3300 XL · PRECISION MICROMETER

330185-01

330185-01 — A precision micrometer for controlled target positioning during 3300 XL proximity transducer system verification.

PRODUCTPrecision micrometer
SCALE RANGE0–1 in
TARGET4140 steel · 30.5 mm
USETransducer verification
MANUFACTURERBently Nevada · Baker Hughes
CONDITION / WARRANTYOriginal New · One-Year Warranty
ISO CERTIFICATIONISO-Certified Product
VERIFICATION● Product photos and videos provided after inquiry
REQUEST A QUOTE
Jetzt anfragen
MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.
BENTLY NEVADA ● 3300 XL VERIFICATION KIT
PRECISION MICROMETER

330185-01

English units · 0–1 in scale · 30.5 mm target

3300 XL Precision Micrometer

VERIFICATION ROLE
330185-01 — A controlled mechanical target-positioning tool for verifying compatible 3300 XL proximity transducer systems.
SCALE OPTION
The 01 option identifies the micrometer with English units and a 0–1 inch measurement range.
👩‍💼
WANT THE BEST PRICE?
Frida
Sales Leader 🏆
EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275
CONFIGURATION DECODING

Model code at a glance

330185
Base model3300 XL Precision Micrometer
01
Scale unitsEnglish units · 0–1 in
MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

3300 XL Verification Kits Official PDF ↗
3300 XL PRECISION MICROMETER

Engineering data at a glance

Click “+” to expand more specifications.

HEIGHT226 mm (8.9 in)
WIDTH274 mm (10.8 in)
LENGTH356 mm (14.0 in)
WEIGHT6.8 kg (14.5 lb)
Dimensions and performance from manufacturer verification-kit data.
Verification setup Confirm the complete transducer system, adapter thread and test conditions before verification.
General Information −
BrandBently Nevada
Part number330185-01
Product type3300 XL Precision Micrometer
Product family3300 XL Monitor and Transducer Verification Kits
Measurement principlePrecision mechanical target positioning
OutputActual target position for comparison with Proximitor Sensor voltage
Verification Performance ＋
ISFActual±5 mV/mil relative to the actual transducer system
DSLActual±0.5 mil relative to the actual transducer system
Measurement basis3300 XL 8 mm 5 m system at 22 ±3°C (72 ±5°F)
Mechanical and Adapter Details ＋
TargetAISI 4140 alloy steel · 30.5 mm (1.20 in) flat target
Micrometer scaleEnglish units · 0–1 in
Adapter thread sizes1/4, 3/8, 1/2, 5/8 in · M8, M10, M14, M16
Case constructionFiberglass and plastic
Verification useAcceptance testing and probe-curve generation for compatible systems
Case Size and Handling ＋
Case size: 226 × 274 × 356 mm (8.9 × 10.8 × 14.0 in). Total system weight: 6.8 kg (14.5 lb).
Source: Bently Nevada 141196 Rev. G. Verification values are relative to the actual compatible transducer system under the manufacturer stated conditions.
