BENTLY NEVADA · 3300 XL DUAL HIGH-PRESSURE FEEDTHROUGH

330162-03-45-45-45-05-05-94-01-02

The 330162-03-45-45-45-05-05-94-01-02 identifies a Bently Nevada 330162 dual triaxial high-pressure feedthrough that routes two probe cables through a pressurized machine casing. The standard family is rated to 2.76 MPa (400 psi) and must match the installed 3300 probe, extension-cable and Proximitor arrangement.

TYPEDual triaxial feedthrough
PRESSURE2.76 MPa (400 psi)
MATERIAL303 stainless steel
BEND RADIUS25.4 mm minimum
MANUFACTURERBently Nevada
CONDITION / WARRANTYOriginal New · One-Year Warranty
ISO CERTIFICATIONISO-Certified Product
VERIFICATIONProduct photos and videos provided after inquiry
REQUEST A QUOTE
Jetzt anfragen
MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.
BENTLY NEVADA ↗3300 XL DUAL HIGH-PRESSURE FEEDTHROUGH
3300 XL HIGH-PRESSURE FEEDTHROUGH SYSTEM

330162-03-45-45-45-05-05-94-01-02

330162

Dual triaxial feedthrough · 2.76 MPa (400 psi) · 303 stainless steel

PRODUCT ROLE

330162-03-45-45-45-05-05-94-01-02 is a dual triaxial high-pressure feedthrough that routes two proximity-probe cables through a pressurized machine casing while maintaining the required transducer-system electrical lengths.

CONFIGURATION NOTE

For 330162-03-45-45-45-05-05-94-01-02, preserve every supplied order-code segment in its original sequence. Confirm the exact label, armor arrangement, cable dimensions, O-ring material, connector genders, total transducer-system lengths and machine fluid or gas compatibility before replacement.

WANT THE BEST PRICE?

Frida

Sales Leader 🏆
ORDER NUMBER BREAKDOWN

How the 330162-03-45-45-45-05-05-94-01-02 reference is structured

330162
Base modelDual triaxial HP feedthrough
03
Armor optionArmor at high-pressure end
45
Dimension 1 length4.5 metres
45
Dimension 2 length4.5 metres
45
Dimension 3 length4.5 metres
05
Dimension 4 length0.5 metre
05
Additional supplied fieldNot defined in the public 330162 pattern
94
O-ring materialFluorocarbon
01
High-pressure connectorFemale miniature coaxial connector
02
Low-pressure connectorMale miniature coaxial connector
MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

Baker Hughes Datasheet 141622 ↗
330162 · DUAL TRIAXIAL HIGH-PRESSURE FEEDTHROUGH

Engineering data at a glance

Confirm the complete order code, cable dimensions, O-ring material and connector arrangement before installation.

TYPEDual triaxial feedthrough
PRESSURE2.76 MPa (400 psi)
MATERIAL303 stainless steel
BEND RADIUS25.4 mm minimum
Baker Hughes Datasheet 141622 states that feedthrough length must match the total transducer-system length and that the selected O-ring must be compatible with the machine gas or fluid.
General Information＋
ManufacturerBently Nevada
Model330162-03-45-45-45-05-05-94-01-02
Product type3300 XL Dual Triaxial High-Pressure Feedthrough
Cable capacityTwo triaxial probe cables
Maximum pressure rating2.76 MPa (400 psi)
Fitting material303 stainless steel
Minimum bend radius25.4 mm (1.00 in)
Humidity100% non-condensing
ORDER NUMBER CHECK＋
Reference sequence330162-03-45-45-45-05-05-94-01-02
Base model330162 · dual feedthrough
Segment handlingKeep all supplied fields in their original order
SYSTEM & ELECTRICAL COMPATIBILITY＋
System roleRoutes two probe cables through a pressurized machine casing
System compatibilityMatch probe, feedthrough, extension cable and Proximitor electrical lengths
Connector ruleProbe side female; Proximitor side male for the usual arrangement
INSTALLATION & REPLACEMENT CHECK＋
O-ring selectionMatch the seal material to the process gas or fluid
Water exposureProtect both cable-to-feedthrough interfaces from water
Replacement limitDo not substitute until the full label and installed transducer chain match
FAQ

Questions Buyers Ask Most

What is 330162-03-45-45-45-05-05-94-01-02 used for?
330162-03-45-45-45-05-05-94-01-02 is a Bently Nevada 330162 dual triaxial high-pressure feedthrough that carries two proximity-probe cables through a pressurized machine casing while preserving the required measurement-system electrical lengths.
How many probe cables does 330162-03-45-45-45-05-05-94-01-02 route?
330162-03-45-45-45-05-05-94-01-02 is built on the 330162 dual-feedthrough configuration and routes two triaxial probe cables; the connected probes, extension cables and Proximitor sensors must form two compatible electrical-length chains.
What pressure and material data apply to 330162-03-45-45-45-05-05-94-01-02?
330162-03-45-45-45-05-05-94-01-02 belongs to the standard high-pressure feedthrough family rated at 2.76 MPa (400 psi), with 303 stainless-steel fitting material and a minimum cable bend radius of 25.4 mm.
Why must the cable lengths be checked for 330162-03-45-45-45-05-05-94-01-02?
330162-03-45-45-45-05-05-94-01-02 replaces part of each extension-cable path, so every ordered feedthrough length must match the total length required by the connected probe and Proximitor sensor system.
How should the connectors be arranged for 330162-03-45-45-45-05-05-94-01-02?
330162-03-45-45-45-05-05-94-01-02 should normally present female connectors toward the probe side and male connectors toward the Proximitor side; confirm both supplied connector options against the installed ClickLoc connections.
What seal condition must be confirmed before installing 330162-03-45-45-45-05-05-94-01-02?
330162-03-45-45-45-05-05-94-01-02 requires an O-ring material compatible with the machine gas or fluid, and both cable-to-feedthrough interfaces must be protected from water to avoid signal degradation.
What information should be supplied when ordering 330162-03-45-45-45-05-05-94-01-02?
For a 330162-03-45-45-45-05-05-94-01-02 inquiry, provide the complete unsplit order code, quantity, nameplate photo, process gas or fluid, operating pressure, cable dimensions, connector genders, probe and Proximitor references, and required system lengths.
CONTACT PRODUCT SPECIALIST

Confirm your 330162-03-45-45-45-05-05-94-01-02 configuration with Frida

Share the complete model and application details for compatibility, availability and lead-time checking.

CHOOSE A DIRECT CONTACT METHOD
DATA SHEET

Product Information for
330162-03-45-45-45-05-05-94-01-02

Baker Hughes Datasheet 141622 Rev. G provides manufacturer-reference information for the 330162 dual triaxial high-pressure feedthrough, including ordering fields, pressure rating, O-ring options and connector requirements.

Official Baker Hughes datasheet

The official 3300 XL High-Pressure Feedthrough Datasheet 141622 covers the 330162 family and its manufacturer-defined ordering information. Open the official PDF to verify the complete supplied reference before installation or replacement.

OPEN OFFICIAL MANUAL PDF

Contact to Get Support

Send the complete model, quantity, and your technical or purchasing question.

Source: Baker Hughes 3300 XL High-Pressure Feedthrough Datasheet 141622 Rev. G. Confirm the complete 330162-03-45-45-45-05-05-94-01-02 label and installed transducer-system configuration before ordering.
