 /Siemens 6ES7288-5DT04-0AA0 SIMATIC S7-200 SMART SB DT04 Digital I/O Signal Board
Siemens 6ES7288-5DT04-0AA0 SIMATIC S7-200 SMART SB DT04 Digital I/O Signal Board
Siemens 6ES7288-5DT04-0AA0 SIMATIC S7-200 SMART SB DT04 Digital I/O Signal Board
Siemens 6ES7288-5DT04-0AA0 SIMATIC S7-200 SMART SB DT04 Digital I/O Signal Board

Siemens 6ES7288-5DT04-0AA0 SIMATIC S7-200 SMART SB DT04 Digital I/O Signal Board

SIMATIC S7-200 SMART · SB DT04

6ES7288-5DT04-0AA0

The 6ES7288-5DT04-0AA0 is a Siemens SIMATIC S7-200 SMART SB DT04 signal board with 2 digital inputs and 2 transistor outputs at 24 V DC.

DIGITAL INPUTS2 DI
DIGITAL OUTPUTS2 DQ
SUPPLY24 V DC
OUTPUT RATING0.75 A
MANUFACTURERSiemens
CONDITION / WARRANTYOriginal New · One-Year Warranty
ISO CERTIFICATIONISO-Certified Product
VERIFICATION● Product photos and videos provided after inquiry
REQUEST A QUOTE
Jetzt anfragen
MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.
SIEMENS ● DIGITAL I/O SIGNAL BOARD
SIMATIC S7-200 SMART MODULE

6ES7288-5DT04-0AA0

SB DT04

Digital I/O · 2 DI / 2 DQ

MODULE ROLE
6ES7288-5DT04-0AA0 is a SIMATIC S7-200 SMART SB DT04 digital I/O signal board providing two 24 V DC inputs and two 24 V DC transistor outputs.
CONFIGURATION NOTE
For 6ES7288-5DT04-0AA0, Siemens specifies 2 DI, 2 DQ rated 24 V DC / 0.75 A, a 24 V DC supply range of 20.4 to 28.8 V and typical power loss of 1 W.
👩‍💼
WANT THE BEST PRICE?
Frida
Sales Leader 🏆
EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275
ORDER NUMBER BREAKDOWN

How the order number identifies this module

6ES7288
Product familySIMATIC S7-200
SMART
5DT04
Module type
0AA0
Order suffix
MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

SIMATIC S7-200 SMART ↗
S7-200 SMART DIGITAL I/O

Engineering data at a glance

Click “+” to expand more specifications.

DIGITAL INPUTS2 × 24 V DC
DIGITAL OUTPUTS2 × 24 V DC
OUTPUT CURRENT0.75 A
POWER LOSS1 W typ.
Official Siemens product data.
Official product verification Verify the complete order number 6ES7288-5DT04-0AA0 and all application, wiring and compatibility requirements before ordering.
General Information −
BrandSiemens
Part number6ES7288-5DT04-0AA0
Product typeSB DT04 Digital I/O Signal Board
Product familySIMATIC S7-200 SMART
Mounting styleSignal-board slot
Engineering softwareSTEP 7 Micro/WIN SMART
Digital Inputs and Outputs ＋
Digital inputs2 inputs at 24 V DC
Digital outputs2 transistor outputs at 24 V DC
Output rating0.75 A per specified output
Electrical and Module Data ＋
Supply voltage24 V DC; permissible 20.4–28.8 V
Channel configuration2 inputs at 24 V DC and 2 transistor outputs at 24 V DC
Input thresholdsState 0: max. 5 V; state 1: min. 15 V
Packaging quantity1 piece
Degree of protectionIP20
Environment and Certification ＋
Packaging dimensions and net weight: 13.00 × 11.3 × 0.75 A; 1 W typ.. Country of origin: China.
Source: Siemens official technical datasheet for 6ES7288-5DT04-0AA0.
FAQ

Questions Buyers Ask Most

What I/O does 6ES7288-5DT04-0AA0 add?＋

6ES7288-5DT04-0AA0 adds 2 digital inputs and 2 transistor digital outputs to a compatible SIMATIC S7-200 SMART CPU.

What voltage and output current are specified for 6ES7288-5DT04-0AA0 ?＋

6ES7288-5DT04-0AA0 uses 24 V DC I/O, and its digital outputs are specified at 24 V DC / 0.75 A.

What supply range does 6ES7288-5DT04-0AA0 accept?＋

6ES7288-5DT04-0AA0 uses a 24 V DC supply with a permissible range of 20.4 to 28.8 V.

What input thresholds are specified for 6ES7288-5DT04-0AA0 ?＋

6ES7288-5DT04-0AA0 recognizes state 0 at a maximum of 5 V and state 1 at a minimum of 15 V.

How quickly do the outputs of 6ES7288-5DT04-0AA0 switch?＋

6ES7288-5DT04-0AA0 has specified output delays of up to 2 µs when switching on and 10 µs when switching off.

Where is 6ES7288-5DT04-0AA0 installed?＋

6ES7288-5DT04-0AA0 is installed in the compatible S7-200 SMART signal-board slot; CPU model and available slot must be checked before ordering.

What information is needed to quote 6ES7288-5DT04-0AA0 ?＋

6ES7288-5DT04-0AA0 should be quoted with the complete model, CPU type, input sensors, output loads, quantity and delivery destination.

CONTACT PRODUCT SPECIALIST

Check your configuration with Frida

Share the complete order number and application details for compatibility, availability and lead-time checking.

CHOOSE A DIRECT CONTACT METHOD
DATA SHEET

Manuals and Official References for
6ES7288-5DT04-0AA0

Official Siemens documentation for the SIMATIC S7-200 SMART SB DT04 digital I/O signal board.

SIMATIC S7-200 SMART SB DT04 Digital I/O

Siemens technical datasheet for 6ES7288-5DT04-0AA0, including 2 DI, 2 DQ, supply, output rating, thresholds and module data.

OFFICIAL DATASHEET

Contact to Get Support

Send the complete model, quantity, and your technical or purchasing question.

Technical statements on this product page are based on publicly available official Siemens manufacturer documentation.

S7-200 SMART SYSTEM RELATIONSHIP

How SB DT04 Fits into the SIMATIC S7-200 SMART System

Siemens is the brand; SIMATIC S7-200 SMART is the PLC family; and 6ES7288-5DT04-0AA0 is the SB DT04 2AI/1AO analog I/O module.

Siemens · BRAND
SIMATIC S7-200 SMARTPLC FAMILY · AUTOMATION SYSTEM
DIGITAL I/O SIGNAL BOARD

SB DT04

SB DT04 adds two 24 V DC digital inputs and two 24 V DC transistor outputs to a compatible S7-200 SMART CPU.

ENGINEERING

STEP 7 Micro/WIN SMART

STEP 7 Micro/WIN SMART is used to configure the compatible S7-200 SMART controller and its connected modules.

SIGNAL OPTIONS

24 V DC digital channels

The board provides 2 DI and 2 DQ, with the outputs specified at 24 V DC / 0.75 A.

System relationship: verify the complete module order number, controller compatibility, channel wiring and required analog signal ranges.
