 /Siemens 6ES7288-1CR60-0AA1 SIMATIC S7-200 SMART CPU CR60s Controller
Siemens 6ES7288-1CR60-0AA1 SIMATIC S7-200 SMART CPU CR60s Controller
Siemens 6ES7288-1CR60-0AA1 SIMATIC S7-200 SMART CPU CR60s Controller
Siemens 6ES7288-1CR60-0AA1 SIMATIC S7-200 SMART CPU CR60s Controller

Siemens 6ES7288-1CR60-0AA1 SIMATIC S7-200 SMART CPU CR60s Controller

SIMATIC S7-200 SMART · CPU CR60s

6ES7288-1CR60-0AA1

The 6ES7288-1CR60-0AA1 is a Siemens SIMATIC S7-200 SMART CPU CR60s PLC with 36 digital inputs, 24 relay outputs and integrated RS485 serial communication.

INPUTS36 DI
OUTPUTS24 Relay
SUPPLY85–264 VAC
MEMORY20 KB
MANUFACTURERSiemens
CONDITION / WARRANTYOriginal New · One-Year Warranty
ISO CERTIFICATIONISO-Certified Product
VERIFICATION● Product photos and videos provided after inquiry
REQUEST A QUOTE
Jetzt anfragen
MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.
SIEMENS ● STANDARD CPU
SIMATIC S7-200 SMART PLC

6ES7288-1CR60-0AA1

CPU CR60s

Standard CPU · AC/DC/Relay

MEASUREMENT ROLE
6ES7288-1CR60-0AA1 is a standard SIMATIC S7-200 SMART CPU with onboard 36 DI at 24 V DC, 24 relay outputs rated 2 A and integrated communication interfaces.
CONFIGURATION NOTE
For 6ES7288-1CR60-0AA1, Siemens specifies an 85–264 V AC, 47–63 Hz supply, 20 KB program/data memory and one onboard RS485 serial interface.
👩‍💼
WANT THE BEST PRICE?
Frida
Sales Leader 🏆
EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275
ORDER NUMBER BREAKDOWN

How the order number identifies this CPU

6ES7288
Product familySIMATIC S7-200
SMART
1CR60
CPU version
0AA1
Order suffix
MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

SIMATIC S7-200 SMART ↗
S7-200 SMART CPU FAMILY

Engineering data at a glance

Click “+” to expand more specifications.

LENGTH11 cm
WIDTH10 cm
HEIGHT8.1 cm
WEIGHT0.620 kg
Official Siemens product data.
Official product verification Verify the complete order number 6ES7288-1CR60-0AA1and electrical version against the current official Siemens datasheet before ordering.
General Information −
BrandSiemens
Part number6ES7288-1CR60-0AA1
Product typeCPU CR60s AC/DC/Relay
Product familySIMATIC S7-200 SMART
Mounting styleDIN rail
Engineering softwareSTEP 7 Micro/WIN SMART
Onboard I/O and Memory ＋
Digital inputs36 DI, 24 V DC
Digital outputs24 relay outputs, 2 A
Program / data memory20 KB total
Performance and Communication ＋
Bit execution time150 ns
ExpansionFixed onboard I/O; no expansion modules
Serial interfaceRS485
Power loss20 W maximum
Functions6 counters, up to 8 PID loops
Environment and Certification ＋
Operating temperature: −20 to +60 °C for horizontal mounting and −20 to +50 °C for vertical mounting. Maximum relative humidity is 95%, non-condensing.
Source: Siemens official technical datasheet for 6ES7288-1CR60-0AA1.
FAQ

Questions Buyers Ask Most

Which machine applications suit 6ES7288-1CR60-0AA1?＋

6ES7288-1CR60-0AA1 suits larger standalone machines that need many fixed digital signals, relay switching and serial device integration without expansion modules.

What fixed I/O capacity is built into 6ES7288-1CR60-0AA1?＋

6ES7288-1CR60-0AA1 includes 36 digital inputs at 24 V DC and 24 relay outputs, for 60 onboard digital points.

How should the relay loads on 6ES7288-1CR60-0AA1 be divided?＋

The 24 relay outputs on 6ES7288-1CR60-0AA1 should be grouped by voltage and inrush category; use external protection or interposing relays for loads outside the permitted contact rating.

What cabinet space and dissipation apply to 6ES7288-1CR60-0AA1?＋

6ES7288-1CR60-0AA1 is approximately 175 × 100 × 81 mm, weighs about 620 g and has roughly 20 W maximum power loss.

What memory and high-speed counting does 6ES7288-1CR60-0AA1 support?＋

6ES7288-1CR60-0AA1 provides 12 KB program plus 8 KB data memory and four single-phase counters up to 100 kHz, with two A/B-phase counters up to 50 kHz.

Can 6ES7288-1CR60-0AA1 connect directly to PROFINET?＋

6ES7288-1CR60-0AA1 is a serial-only compact CPU with onboard RS485; it does not provide onboard PROFINET, so use a gateway or select a network-capable CPU.

Which project data are needed to quote 6ES7288-1CR60-0AA1?＋

To quote 6ES7288-1CR60-0AA1, send the nameplate, firmware, supply voltage, 36-input/24-output assignment, relay-load details, RS485 topology, backup status, quantity and destination.

CONTACT PRODUCT SPECIALIST

Check your configuration with Frida

Share the complete order number and application details for compatibility, availability and lead-time checking.

CHOOSE A DIRECT CONTACT METHOD
DATA SHEET

Manuals and Official References for
6ES7288-1CR60-0AA1

Official Siemens documentation for the SIMATIC S7-200 SMART CPU CR60s.

SIMATIC S7-200 SMART CPU CR60s

Siemens technical datasheet for 6ES7288-1CR60-0AA1, including electrical, I/O, memory, communication, environmental, dimension and weight data.

OFFICIAL DATASHEET

Contact to Get Support

Send the complete model, quantity, and your technical or purchasing question.

Technical statements on this product page are based on publicly available official Siemens manufacturer documentation.

S7-200 SMART SYSTEM RELATIONSHIP

How CPU CR60s Fits into the SIMATIC S7-200 SMART System

Siemens is the brand; SIMATIC S7-200 SMART is the PLC family; and 6ES7288-1CR60-0AA1 is the CPU CR60s AC/DC/Relay model with onboard I/O and communication.

Siemens · BRAND
SIMATIC S7-200 SMARTPLC FAMILY · AUTOMATION SYSTEM
PROCESSING CORE

CPU CR60s

CPU CR60s executes the user program and manages its onboard 36 digital inputs and 24 relay outputs.

ENGINEERING

STEP 7 Micro/WIN SMART

STEP 7 Micro/WIN SMART is used to configure, program and commission the S7-200 SMART CPU.

COMMUNICATION

RS485 serial communication

The integrated RS485 port supports PPI, Modbus RTU, USS and free-port communication.

System relationship: verify the complete CPU order number, power version, I/O needs and the fixed onboard I/O and RS485 communication requirements.
APPLICATION AREAS

Application mind map for the S7-200 SMART CPU CR60s

Machine ControlLogic and sequence control for compact machines
Packaging LinesOnboard digital I/O and transistor switching
APPLICATION CENTER CPU CR60s Compact PLC automation
Building SystemsControl of pumps, fans and auxiliary equipment
OEM EquipmentCost-effective automation for production equipment
