 /Siemens 6ES5316-8MA12 SIMATIC S5 IM 316 Interface Module
Siemens 6ES5316-8MA12 SIMATIC S5 IM 316 Interface Module
Siemens 6ES5316-8MA12 SIMATIC S5 IM 316 Interface Module
Siemens 6ES5316-8MA12 SIMATIC S5 IM 316 Interface Module

Siemens 6ES5316-8MA12 SIMATIC S5 IM 316 Interface Module

Siemens SIMATIC S5 · IM 316 Interface Module

6ES5316-8MA12

The 6ES5316-8MA12 is a Siemens SIMATIC S5 IM 316 interface module for connecting expansion tiers. Siemens specifies a 2.5 A maximum current supply to an expansion unit, typical 27 mA consumption from the CPU +9 V supply, and a maximum of four interface modules per PLC.

HEIGHT135 mm
WIDTH45.4 mm
DEPTH39 mm
WEIGHT≈120 g
MANUFACTURERSiemens
CONDITION / WARRANTYOriginal New · One-Year Warranty
ISO CERTIFICATIONISO-Certified Product
VERIFICATION● Product photos and videos provided after inquiry
REQUEST A QUOTE
Jetzt anfragen
MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.
SIEMENS ● SIMATIC S5 IM 316 INTERFACE MODULE
Siemens SIMATIC S5

6ES5316-8MA12

SIMATIC S5 · IM 316 Interface Module

SIMATIC S5 · IM 316 Interface Module

PRODUCT ROLE
6ES5316-8MA12 is the Siemens IM 316 interface module for SIMATIC S5-100U expansion tiers. It links the central controller with expansion units in a multi-tier configuration.
TECHNICAL CONTEXT
For 6ES5316-8MA12, Siemens specifies a maximum of four IM 316 modules per PLC, up to 2.5 A current supply to the expansion unit, and a typical 27 mA draw from the CPU +9 V supply.
👩‍💼
