25B-D6P0N104 Specifications

25B-D6P0N104 Description

The 525 25B-D6P0N104 AC Drives are acompact, cost-effective drive offering embedded EtherNet/IP™ communications ideal for integrated applications. Capabilities include V/Hz, sensorless and closed loop velocityvector control and permanent magnet motor control, USB programming and safety features with an innovative modulardesign to support easy configuration up to 22kW.

25B-D6P0N104 Alternative names

25B-D6P0N104 FAQ

What is the 25B-D6P0N104 AC Drive?

The 25B-D6P0N104 is a 525 AC Drive. It is a compact, cost-effective drive with embedded EtherNet/IP™ communications, designed for integrated applications requiring motor speed and torque control.

What does the part number 25B-D6P0N104 signify?

The part number breaks down as follows:
25B: 525 Series
D: 380...480V AC, 3 Phase voltage class
6P0: 6.0 Amps output current
N: No filter (EMC filtering options)
104: Frame A, IP20 NEMA/Open Type enclosure with Standard interface module

What types of motor control does this drive support?

The PowerFlex 525 drive supports multiple control modes, including:
V/Hz (Volts per Hertz): Standard control for general-purpose applications
Sensorless Vector Control: Provides better torque performance without a feedback device
Closed Loop Velocity Vector Control: Requires an encoder feedback device for high-precision speed and torque control
Permanent Magnet Motor Control: For use with permanent magnet motors

What communication capabilities does this drive have?

The drive features embedded EtherNet/IP™ communications, allowing direct integration architecture systems. This supports seamless configuration, control, and data collection over standard Ethernet networks.

What are the power ratings for Normal Duty and Heavy Duty?

The 25B-D6P0N104 provides 3 Hp (2.2 kW) for both Normal Duty and Heavy Duty applications. This indicates the drive is capable of handling continuous and overload current requirements for typical industrial loads without derating.
