IC695CPE330 - GE Programmable Controller CPU

GE IC695CPE330 Programmable Controller CPU

Sales Manager: Frida

Email: sales5@mooreplc.com

The PACSystems* RX3i IC695CPE330 is a richly featured programmable controller CPU equipped with a 1GHz dual-core microprocessor, 64Mbytes of built-in program memory and two independent high-speed Ethernet interfaces. It is ideally suited for multi-tier communications and for synchronizing large amounts of data. Its metal housing provides superior noise immunity.
The IC695CPE330 is programmed and configured over Ethernet via GE’s Proficy* Machine Edition (PME) software. It resides in the RX3i main rack and supports all RX3i I/O and Intelligent Option modules, up to 32K I/O points.

Form Factor: Backplane
Storage: 64MB
I/O:  32k Bits Discrete I/O
32k Words for Analog I/O
Field Agent Support: External
USB Interface: 1 USB-A 2.0
Memory Card: 1 CFast (Very high speed Compactflash)‡
Environmental: 0°C to 60°C

Q: What are the key features of the IC695CPE330?

A: The IC695CPE330 features a 1 GHz dual-core processor, 64 MB of user memory, and supports up to 32K discrete and analog I/O points. It has two independent Ethernet ports and a metal housing for superior noise immunity.

Q: How many program blocks does the CPU support?

A: It supports up to 512 program blocks (with newer firmware supporting up to 768 blocks), each with a capacity of up to 128 KB.

Q: Does the IC695CPE330 support Gigabit Ethernet?

A: Yes, both embedded Ethernet ports support 10/100 Mbps and 1 Gbps transmission rates.
