SYSTEM ROLE
RC Snubber Board
Provides the snubber-capacitor network for the SCR and diode power devices on one phase of a 620 frame source bridge.
IS200RCSBG1B is a GE RC snubber board used on one phase of a 620 frame SCR/diode source bridge. GE instruction GEI-100295 identifies one board per bridge and twelve capacitors arranged as six pairs; confirm the complete G1B revision and installed bridge documentation before replacement.
Click “+” to expand more specifications.
Official manufacturer-documentation status for GE IS200RCSBG1B.
No current official IS200RCSBG1B product datasheet was located in the manufacturer's public documentation. For product documentation and compatibility details, please contact Product Specialist Frida.
CONTACT FRIDASend the complete model, quantity, and your technical or purchasing question.
The product identification on this page follows the available GE manufacturer documentation; request exact current IS200RCSBG1B documentation for revision-specific replacement verification.
GE is the manufacturer brand; GE Mark VI is the product family; and IS200RCSBG1B is the RC Snubber Board used on one phase of the source bridge.
Provides the snubber-capacitor network for the SCR and diode power devices on one phase of a 620 frame source bridge.
The board uses twelve capacitors arranged as six pairs; documented capacitance is 0.095–0.150 µF.
Do not substitute another board without checking the complete G1B revision, bridge phase and installed 620 frame documentation.
A clear workflow for sourcing, verification, shipment preparation, delivery and product assurance.
Include the complete part number, quantity and delivery destination.
