Product Overview

The GE Fanuc IC5002TAW1000 is a 12-inch industrial panel computer supplied as a CIMPLICITY Machine Edition development and runtime station. Its catalog configuration includes a 750 MHz processor, 128 MB RAM, a 13 GB hard drive, Microsoft Windows 2000, a floppy drive and a read-only CD-ROM. Unlike an unbundled IC5002 station, the IC5002TAW1000 was supplied with CIMPLICITY Machine Edition View and Logic development and runtime functionality for applications with up to 8000 I/O points. This allowed engineering work and runtime operation to be performed on the same industrial computer. The IC5002 platform uses a 12.1-inch TFT resistive touchscreen with 800 × 600 SVGA resolution. Its compact panel-mount format is suited to local machine control, commissioning and maintenance stations where panel space is limited.

Technical Specifications

Parameter	Specification
Manufacturer	GE Fanuc Automation
Complete catalog number	IC5002TAW1000
Product family	CIMPLICITY Station / IC5002 Intelligence Panel PC
Configuration	Standard bundled development and runtime station
Nominal display size	12 inches
Native resolution	800 × 600 pixels, SVGA
Displayed colors	256K
Display brightness	300 cd/m², downward adjustable
Display video memory	2 MB SDRAM
Processor speed	750 MHz
Installed memory	128 MB RAM
Hard-disk capacity	13 GB
Operating system	Microsoft Windows 2000
Optical drive	Read-only CD-ROM
Floppy drive	3.5-inch floppy drive
Included application software	CIMPLICITY Machine Edition View and Logic
Included software functions	Development and runtime
Licensed I/O configuration	8000 I/O
Ethernet interfaces	2 × 10/100Base-T RJ45
Parallel interface	LPT1
Expansion capacity	2 shared ISA/PCI slots
Maximum expansion-card length	290 mm
AC input range	100–240 VAC
Input frequency	50–60 Hz
Power-supply rating	100 W
Power consumption	48 W typical; 60 W maximum

Features

-12.1-inch TFT color touchscreen
-SVGA 800 × 600 native resolution
-Analog five-wire resistive touch input
-750 MHz processor
-8000 I/O configuration
-Read-only CD-ROM drive
-3.5-inch floppy drive
-Dual 10/100Base-T Ethernet
-Two USB interfaces
-Three external RS-232 ports
-NEMA 4/IP65 front protection

Application Areas
Machine HMI development and runtime stations
Production equipment operator panels
Automation commissioning workstations
Maintenance and diagnostic terminals
Replacement of installed IC5002TAW1000 systems

Brand	GE
Part number	IC5002TAW1000
Origin	USA
Description	12-inch industrial panel computer
Shipping Port	Xiamen，China
Payment	T/T
Lead Time	In stock
Shipment	DHL,UPS,FEDEX,TNT,EMS,SF
Service	One-year warranty

Model Benefits

The product offers a number of benefits, including:
-Combines project development and runtime operation
-Supports applications with up to 8000 I/O points
-Compact panel footprint
-Integrated touchscreen operation
-Multiple industrial communication interfaces
-Retains the original Windows 2000 environment
-Supports controlled replacement of an installed station

Frequently asked questions

1. Which software was supplied with IC5002TAW1000?
The catalog lists this model with CIMPLICITY Machine Edition View and Logic development and runtime functionality for an 8000 I/O configuration. This distinguishes it from the IC5002TAW0000 unbundled hardware version.

2. Does replacement hardware automatically include a usable Machine Edition license?
Not necessarily. The original catalog configuration included licensed software, but a used or replacement computer may not retain a valid authorization. Engineers should verify the installed software version, license files, hardware-bound authorization and recovery media before commissioning the unit.

3. What should be backed up before replacing the station?
Create a verified image of the complete hard drive. Preserve the Machine Edition project, runtime files, PLC targets, communication drivers, Windows settings, IP configuration, computer name, touchscreen calibration and all software-license records.
