 /Emerson KJ1611X1-FD1 12P4473X032 DeltaV RM100-24TX Smart Network Switch
Emerson KJ1611X1-FD1 12P4473X032 DeltaV RM100-24TX Smart Network Switch
Emerson KJ1611X1-FD1 12P4473X032 DeltaV RM100-24TX Smart Network Switch
Emerson KJ1611X1-FD1 12P4473X032 DeltaV RM100-24TX Smart Network Switch

Emerson KJ1611X1-FD1 12P4473X032 DeltaV RM100-24TX Smart Network Switch

DELTAV RM100-24TX SMART NETWORK SWITCH

KJ1611X1-FD1 12P4473X032

The complete KJ1611X1-FD1 12P4473X032 is an Emerson DeltaV RM100-24TX network switch with 24 Fast Ethernet copper ports and two copper/SFP combo uplinks. It has a fixed port configuration for rack-mounted DeltaV network installations.

COPPER PORTS24 × 10/100
UPLINKS2 combo
PLATFORMDeltaV
CONSTRUCTIONFixed ports
MANUFACTUREREmerson
PRODUCT TYPEDeltaV RM100-24TX Smart Network Switch
CONDITION / WARRANTYOriginal New · One-Year Warranty
VERIFICATIONPhotos and video after inquiry
REQUEST A QUOTE
Jetzt anfragen
MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.
Emerson ● DELTAV RM100-24TX · SMART NETWORK SWITCH
EMERSON DELTAV RM100 SERIES

KJ1611X1-FD1 12P4473X032

24 FAST ETHERNET PORTS

24 copper ports · Two combo uplinks · Fixed configuration

PRODUCT ROLE
KJ1611X1-FD1 12P4473X032 is an Emerson DeltaV RM100-24TX Smart Network Switch. Its 24 copper access ports operate at 10/100 Mbps; the two combo uplinks provide copper or SFP connectivity.
INSTALLATION CHECK
Match the complete hardware reference, network design, power connection and installed transceivers before replacement.
MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

Emerson KJ1611X1-FD1 12P4473X032
DeltaV Smart Network Switch

Engineering data at a glance

Expand the groups for network, power and rack-installation data.

PORTS24 × RJ45
SPEED (Mbps)10/100
UPLINKS2 × GbE
POWER16 W
Fixed-port configurationRM100-24TX is not modular. VE6049 expansion modules do not apply to this fixed-port switch.
GENERAL INFORMATION −
BrandEmerson
Part numberKJ1611X1-FD1 12P4473X032
Product typeDeltaV RM100-24TX Smart Network Switch
Product lineDeltaV RM100
Copper access ports24 × RJ45, 10/100 Mbps
Uplink ports2 copper/SFP combo uplinks
Copper uplink speed10/100/1000 Mbps
Port constructionFixed, non-modular
Power consumption16 W
Weight4.02 kg
Mounting19-inch control cabinet
POWER & ENVIRONMENT＋
Operating supply100–240 VAC, 47–63 Hz
Operating temperature0 to +50 °C
ProtectionIP20
NETWORK CONFIGURATION＋
The fixed RM100-24TX configuration provides copper access connections and two combo uplinks. Use compatible VE6050-series transceivers where an optical uplink is required. VE6049 expansion modules cannot be installed in this switch.
Source:Emerson DeltaV Smart Switches Product Data Sheet, March 2016, RM100-24TX / VE6046 specifications and ordering information, pages 12 and 24.
