Det-Tronics EQ3700DW 007371-003 8-Channel DCIO Module

Det-Tronics EQ3700DW 007371-003 8-Channel DCIO Module

DET-TRONICS EQ3700 · 8-CHANNEL DCIO MODULE

EQ3700DW 007371-003

The EQ3700DW 007371-003 is a Det-Tronics Eagle Quantum Premier 8-channel discrete input/output module for continuously supervised field-device I/O.

CHANNELS8 I/O
VOLTAGE24 VDC
TEMPERATURE–40 TO +85 °C
SHIP WEIGHT0.90 KG
MANUFACTURERDet-Tronics
CONDITION / WARRANTYOriginal New · One-Year Warranty
ISO CERTIFICATIONISO-Certified Product
VERIFICATION● Product photos and videos provided after inquiry
REQUEST A QUOTE
Jetzt anfragen
MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.
Det-Tronics ● 8-CHANNEL DCIO MODULE
DET-TRONICS EAGLE QUANTUM PREMIER DCIO MODULE

EQ3700DW 007371-003

8 CHANNELS · CONFIGURABLE INPUT OR OUTPUT

24 V DC NOMINAL · CONTINUOUS I/O SUPERVISION · LON SLC

MODEL ROLE
EQ3700DW 007371-003 is a Det-Tronics Eagle Quantum Premier discrete I/O module with eight independently configurable input or output channels.
TECHNICAL CONTEXT
For EQ3700DW 007371-003, each channel can be configured as a supervised or unsupervised input or output, with individual active and fault indicators.
👩‍💼
WANT THE BEST PRICE?
Frida
Sales Leader 🏆
EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275
MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

Det-Tronics EQ3700 DCIO ↗
EQ3700DW 007371-003 8-CHANNEL DCIO MODULE

Engineering data at a glance

Click “+” to expand more specifications.

CHANNELS8 I/O
VOLTAGE24 VDC
TEMPERATURE–40 to +85 °C
SHIP WEIGHT0.90 kg
Exact-model part number, approvals and ship weight are from the official Det-Tronics product catalog for EQ3700DW.
Exact-model configuration EQ3700DW 007371-003 is the exact DIN-rail model with part number 007371-003. Match the eight configurable I/O channels, 18 to 30 Vdc input and FM/CSA/ATEX/IECEx approval set.
GENERAL INFORMATION −
BrandDet-Tronics
Part number007371-003
Product typeDiscrete Input/Output module
Product familyEagle Quantum Premier
I/O channels8 × configurable input/output
Channel operationSupervised or unsupervised
Nominal input voltage24 Vdc nominal
Input voltage range18 to 30 Vdc
SLC communication78.5 kbps · transformer-isolated
Operating temperature–40 to +85 °C
ApprovalsFM · CSA · ATEX · IECEx
Mounting / materialDIN rail · Aluminum
I/O CONFIGURATION ＋
Independent channels8 configurable I/O points
Channel modeInput or output
Point styleSupervised or unsupervised
Point typesAlarm, supervisory, notification, releasing or dry contact
Channel indicationIndividual active and fault indicators
ELECTRICAL & ENVIRONMENT ＋
Part number007371-003
MaterialAluminum
Operating temperature–40 to +85 °C
Terminal wire range12 to 18 AWG · 4 to 0.75 mm²
System requirementMeets NFPA 72 requirements
Source: The official Det-Tronics product page, exact specification sheet and product catalog document the eight-channel I/O capability, electrical ratings and exact EQ3700DW ordering data shown above.
FAQ

Questions Buyers Ask Most

What type of product is EQ3700DW 007371-003 ?＋

EQ3700DW 007371-003 is an 8-channel discrete input/output module in the Det-Tronics Eagle Quantum Premier system.

How many I/O channels does EQ3700DW 007371-003provide?＋

EQ3700DW 007371-003 provides eight independent channels, each configurable as an input or an output.

How can each channel on EQ3700DW 007371-003 be configured?＋

EQ3700DW 007371-003 supports supervised or unsupervised point styles and alarm, supervisory, notification, releasing or dry-contact functions.

What power and temperature ratings apply to EQ3700DW 007371-003?＋

EQ3700DW 007371-003 accepts 24 Vdc nominal over an 18 to 30 Vdc range and operates from –40 to +85 °C.

What should be checked before ordering EQ3700DW 007371-003?＋

Confirm the complete EQ3700DW 007371-003 designation and part number 007371-003, DIN-rail mounting, eight-channel I/O requirement, approval set and operating environment.

CONTACT PRODUCT SPECIALIST

Check your configuration with Frida

Share the complete designation, part number 007371-003 and required I/O, approval and power details for availability and lead-time checking.

CHOOSE A DIRECT CONTACT METHOD
DATA SHEET

Product Information for
EQ3700DW 007371-003

Official manufacturer documentation for Det-Tronics EQ3700DW, part number 007371-003.

Official datasheet status

The official Det-Tronics specification sheet and product catalog identify EQ3700DW as an 8-channel DCIO module, part number 007371-003, with DIN-rail mounting and FM/CSA/ATEX/IECEx approvals.

OPEN OFFICIAL DATA SHEET

Contact to Get Support

Send the complete model, quantity, and your technical or purchasing question.

Technical statements on this product page are based on the official Det-Tronics EQ3700 product page, exact specification sheet and product catalog.

DET-TRONICS EQP DCIO SYSTEM RELATIONSHIP

How EQ3700DW 007371-003 Expands Supervised System I/O

Det-Tronics is the manufacturer brand; Eagle Quantum Premier is the system family; and EQ3700DW 007371-003 is an 8-channel Discrete Input/Output module identified by part number 007371-003.

Det-Tronics · BRAND
Eagle Quantum PremierDiscrete Input/Output module
SYSTEM ROLE

Eight-channel configurable DCIO module

Expands Eagle Quantum Premier field I/O with eight individually configurable input or output channels.

CONFIGURABLE I/O

8 independent channels

Each channel supports supervised or unsupervised operation and provides individual active and fault indication.

ORDER DATA

007371-003 · 24 Vdc nominal · DIN rail

Match the complete model designation and part number before selecting a replacement.

System relationship: verify part number 007371-003, eight-channel I/O configuration, 18 to 30 Vdc input and the required approval set.
APPLICATION AREAS

Application map for EQ3700DW 007371-003

Supervised Field I/OConfigure eight independent channels as supervised or unsupervised inputs or outputs
Eagle Quantum Premier IntegrationLON SLC · transformer-isolated · individual channel indication
APPLICATION CENTER EQ3700DW 007371-003 Eagle Quantum Premier · Part 007371-003
DIN-Rail InstallationDIN-rail mounting, 24 Vdc nominal input and plug-in terminals for 12 to 18 AWG wire
Exact-Model ReplacementCheck the complete EQ3700DW designation, part number 007371-003, I/O function, approval set, supply range and environmental requirements before replacement.
