The ABB CI512-ETHCAT is an AC500/S500 EtherCAT slave interface with two 100BASE-TX ports, 8 digital inputs, 8 digital outputs and 8 software-configurable digital I/O channels. S500 expansion requires device index C0 or above.
EtherCAT slave interface · 2-port 100BASE-TX switch · 8 DI · 8 DO · 8 configurable digital I/O.
CI512-ETHCAT connects integrated and compatible S500 digital I/O to an EtherCAT master through two switched RJ45 line ports.
Confirm order number 1SAP221000R0001, device index, EtherCAT master/ESI project, line position, 24 V DC wiring and digital channel mapping before replacement.
Source: ABB CI512-ETHCAT data sheet 3ADR010008, ABB product page for 1SAP221000R0001, and ABB Automation Builder compatibility information. Values apply under ABB’s stated operating conditions.
Official ABB product and technical data for CI512-ETHCAT, complete order number 1SAP221000R0001.
ABB documents CI512-ETHCAT as an EtherCAT slave communication interface with 8 DI, 8 DO and 8 configurable digital I/O channels. It uses two 10/100 Mbit/s RJ45 ports and supports up to 10 S500 expansion modules only on device index C0 or above.
OFFICIAL DATASHEET ↗Send the complete model, quantity, network configuration and your technical or purchasing question.
✉ EMAILSource: ABB 3ADR010008 and ABB official product page for 1SAP221000R0001; lifecycle phase is listed as Active.
ABB ↗ is the brand, AC500/S500 is the automation platform, CI512-ETHCAT is the complete module model, EtherCAT slave communication interface is the product type, and 1SAP221000R0001 is the standard order configuration.
EtherCAT communication with a compatible master.
Two switched RJ45 Ethernet ports.
8 DI, 8 DO and 8 configurable digital channels.
Up to 10 S500 modules on device index C0 or above.
Exchanges process and service data with a compatible EtherCAT master.
Eight DC channels are assigned as inputs or outputs by software.
Combines onboard digital channels with compatible S500 expansion.
The two RJ45 ports form one switched EtherCAT device connection.
A clear workflow for sourcing, verification, shipment preparation, delivery and product assurance.
Include the complete part number, quantity and delivery destination.
