ABB ● ACS580 GENERAL PURPOSE WALL-MOUNTED DRIVE
ABB ACS580 REFERENCE

ACS580-01-145A-4

OFFICIAL ABB DOCUMENTATION

Exact label · installed ABB system · identifier segment · rating and nameplate record

PRODUCT ROLE
ACS580-01-145A-4 is an ABB low-voltage AC general purpose wall-mounted drive. ABB identifies this exact type as a 400 V, frame R6 low-voltage AC general purpose wall-mounted drive in the ABB ACS580 general purpose drive family.
INSTALLATION CHECK
Confirm ACS580-01-145A-4, frame R6, the complete type-code marking, power isolation, ratings, dimensions and mechanical fit before replacement.
👩‍💼
WANT THE BEST PRICE?
Frida
Sales Leader 🏆
EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275
ORDER NUMBER BREAKDOWN

How the ACS580-01-145A-4 identifier is structured

ACS580-01-145A-4 follows ABB's published type-designation structure. ACS580 identifies the product series; 01 identifies wall-mounted construction; 145A-4 identifies 145 A nominal current and the 400 V voltage class.

ACS580
Drive familyABB ACS580 general purpose drive family identifier
01
Wall-mounted construction01 = wall-mounted drive construction
145A-4
Current and voltage rating145A = 145 A nominal output current; 4 = 400 V voltage class
MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

ABB ACS580 general purpose drive family
ACS580-01-145A-4

Identification data at a glance

ABB official documentation identifies ACS580-01-145A-4 and states the official ratings and physical data shown here.

HEIGHT726.5 mm
WIDTH252 mm
DEPTH369 mm
WEIGHT42.4 kg
Official ABB drive identificationMatch the complete ACS580-01-145A-4 type code and installed general-purpose configuration before ordering.
GENERAL INFORMATION −
BrandABB
Complete referenceACS580-01-145A-4
Product typelow-voltage AC general purpose wall-mounted drive
Official typeACS580-01-145A-4
Rated-voltage class400 V
FrameR6
IEC rating75 kW; 145 A; 400 V
Heavy-duty rating55 kW; 105 A
DocumentationABB manufacturer statement 3AXD10000531006
IDENTIFICATION & COMPATIBILITY ＋
Label evidenceComplete ACS580-01-145A-4 type code as supplied
System evidenceInstalled ACS580 general-purpose configuration
Replacement limitDo not substitute without type code, rating and system confirmation
INSTALLATION & ORDERING ＋
Before ordering or replacement, provide the complete type code, nameplate photographs, quantity and installed ACS580 general-purpose configuration.
Source: ABB exact-model manufacturer statement 3AXD10000531006 and ACS580 catalog; verify the installed drive nameplate before replacement.
